Specification
| Part No. | Male/Female | Material | Treatment | Wire Range (AWG) | Dimension (mm) | Thickness (mm) | Q’TY | Remarks | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| D | H | W | L | E | ||||||||
| 1767 | Female | Brass | -0 | 16-20 | / | 3.0 | 7.65 | 16.6 | 7.7 | 0.4 | 2500 | TAB/0.8 |
| Part No. | Male/Female | Material | Treatment | Wire Range (AWG) | Dimension (mm) | Thickness (mm) | Q’TY | Remarks | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| D | H | W | L | E | ||||||||
| 1767 | Female | Brass | -0 | 16-20 | / | 3.0 | 7.65 | 16.6 | 7.7 | 0.4 | 2500 | TAB/0.8 |
